| No. of channels | 6 |
| No. of inputs | 12 |
| Mic input | 1 mV/6.6 kΩ, 6 x 3-pole XLR, bal. |
| Line input | 100 mV/10 kΩ, 6 x RCA L/R |
| CD input | - |
| Phono input | - |
| Tape (play) | - |
| Aux input | - |
| Insert input | - |
| Effect return | - |
| Master output | 1 V/600 Ω, 1 x RCA L/R
1 x 3-pole XLR L/R, bal. |
| Record output | 310 mV/600 Ω, 1 x RCA L/R |
| Monitor output | - |
| Booth output | - |
| Aux output | - |
| Insert output | - |
| Effect send | - |
| Control room | - |
| Tape (rec) | - |
| Headphones | > 8 Ω, 1 x 6.3 mm jack |
| Gooseneck lamp | - |
| WiFi | - |
| USB | - |
| Frequency range | 20-20,000 Hz |
| THD | 0.1% |
| S/N ratio | 62 dB, unweighted |
| Crosstalk | - |
| Equalizer bass | ±12 dB/50 Hz |
| Equalizer midrange | ±12 dB/1 kHz |
| Equalizer treble | ±12 dB/10 kHz |
| equalizer | - |
| Talkover | -12 dB, manual |
| Phantom power | - |
| Crossfader | - |
| Media player | - |
| Amplifier | - |
| Power supply | ∼ 230 V/50 Hz/12 VA |
| Mains voltage | ∼ 230 V |
| Mains frequency | 50 Hz |
| Power consumption, operation | 12 VA |
| Operating voltage (possible alternative) | - |
| Power supply (possible alternative) | - |
| Admiss. ambient temp. | 0-40 °C |
| Width | 482 mm |
| Height | 47 mm |
| Depth | 208 mm |
| Rack spaces, RS | 1 |
| Weight | 2.8 kg |
