| Active/passive |
passive
|
| Transmission technology |
100 V
|
| Total power rating |
10 W
|
| Power rating (RMS) |
10/5/2.5 W
|
| Frequency range |
350-10,000 Hz
|
| Number of speakers |
1
|
| SPL |
110 dB (1 W/1 m) 84 dB (EN, 1 W/4 m)
|
| Max. rated SPL |
118 dB (1 m) 97.3 dB (EN, 4 m)
|
| Radiation angle/beam angle |
H180°/V180° (500 Hz) H180°/V180° (1 kHz) H79°/V119° (2 kHz) H30°/V44° (4 kHz)
|
| Radiation angle, horizontal |
180° (500 Hz) 180° (1 kHz) 79° (2 kHz) 30° (4 kHz)
|
| Radiation angle, vertical |
180° (500 Hz) 180° (1 kHz) 119° (2 kHz) 44° (4 kHz)
|
| Features |
EN 54-24 certification
|
| Housing material |
ABS
|
| Colour |
light grey, RAL 7035
|
| Mounting device |
mounting bracket
|
| Protection class |
IP66
|
| Admiss. ambient temp. |
-40 °C to +80 °C
|
| Dimensions |
180 x 120 x 230 mm
|
| Width |
180 mm
|
| Height |
120 mm
|
| Depth |
230 mm
|
| Weight |
1.8 kg
|
| Inputs |
M20 cable gland
|
| Other features |
weatherproof
|
| Packaging dimensions (W x H x L) |
0.175 x 0.175 x 0.267 m
|
| Gross weight |
1.9 kg
|
| Net weight |
1.8 kg
|
