| No. of channels | 6 |
| No. of inputs | 12 |
| Mic input | 1.5 mV, 2 x 6.3 mm jack |
| Line input | 150 mV, 5 x RCA L/R |
| CD input | 150 mV, 1 x RCA L/R |
| Phono input | 3 mV, 2 x RCA L/R |
| Tape (play) | - |
| Aux input | - |
| Insert input | - |
| Effect return | - |
| Master output | 1 V/600 Ω, 1 x 3-pole XLR,
1 x RCA L/R |
| Record output | 0.5 V/600 Ω, 1 x RCA L/R |
| Monitor output | 1 V/600 Ω (zone), 1 x RCA L/R |
| Booth output | 1 V/600Ω, 1 x RCA L/R |
| Aux output | - |
| Insert output | - |
| Effect send | - |
| Control room | - |
| Tape (rec) | - |
| Headphones | ≥ 8 Ω, 1 x 6.3 mm jack |
| Gooseneck lamp | 12 V/0.75 W, 1 x BNC |
| WiFi | - |
| USB | - |
| Frequency range | 20-20,000 Hz |
| THD | 0.1% |
| S/N ratio | 61 dB, unweighted |
| Crosstalk | - |
| Equalizer bass | +12 dB, -12 dB/50 Hz (mic)
+15 dB, -30 dB/50 Hz (channels 1-4) |
| Equalizer midrange | +12 dB, -12 dB/1 kHz (mic)
+15 dB, -30 dB/1 kHz (channels 1-4) |
| Equalizer treble | +12 dB, -12 dB/10 kHz (mic)
+15 dB, -30 dB/10 kHz (channels 1-4) |
| equalizer | - |
| Talkover | -16 dB, automatic |
| Phantom power | - |
| Crossfader | yes |
| Media player | - |
| Amplifier | - |
| Power supply | ∼230 V/50 Hz/20 VA |
| Mains voltage | ∼ 230 V |
| Mains frequency | 50 Hz |
| Power consumption, operation | 20 VA |
| Operating voltage (possible alternative) | - |
| Power supply (possible alternative) | - |
| Admiss. ambient temp. | 0-40 °C |
| Width | 482 mm |
| Height | 177 mm |
| Depth | 105 mm |
| Rack spaces, RS | 4 |
| Weight | 3.6 kg |
