8 pole male cable connector, black-chrome metal housing, chuck type strain relief
The speakON STX Series was especially designed for heavy duty amplifier-loudspeaker applications like professional touring. The extremely rugged and durable STX Seri
Tekniske specifikationer
Title
NLT8MX-BAG
Electrical
Contact resistance
< 2 mΩ (after lifetime) mΩ (inner)
Dielectric strength
4 kVdc (peak)
Insulation resistance
> 10 GΩ
Rated current per contact
40 A rms continuous
Rated current per contact
50 A audiosignal, duty cycle 50 %
Rated voltage
250 V (Insulation)
Attention
speakON is NOT to be used as an AC mains or power supply
connector!
Mechanical
Cable O.D.
8 - 20 mm
Cable retention
≥ 220 N (subject to cable O.D. and material)
Lifetime
> 5000 mating cycles
Wiresize
6 mm²
Wiresize
10 AWG
Environmental
Temperature range
-30 °C to +80 °C
