| Active/passive |
passive
|
| Transmission technology |
100 V
|
| Total power rating |
10 W
|
| Power rating (RMS) |
10/5/2,5 W
|
| Frequency range |
80-19,000 Hz
|
| Number of speakers |
1
|
| Speaker size |
13 cm (5")
|
| SPL |
93 dB (1 W/1 m) 76 dB (EN, 1 W/4 m)
|
| Max. rated SPL |
103 dB (1 m) 88 dB (EN, 4 m)
|
| Radiation angle/beam angle |
H180°/V180° (500 Hz) H180°/V180° (1 kHz) H180°/V1115° (2 kHz) H51°/V68° (4 kHz)
|
| Radiation angle, horizontal |
180° (500 Hz) 180° (1 kHz) 180° (2 kHz) 51° (4 kHz)
|
| Radiation angle, vertical |
180° (500 Hz) 180° (1 kHz) 115° (2 kHz) 68° (4 kHz)
|
| Features |
EN 54-24 certification
|
| Housing material |
ABS
|
| Colour |
White, RAL 9010
|
| Mounting device |
Mounting screws
|
| Protection class |
IP54
|
| Dimensions |
330 x 240 x 83 mm
|
| Width |
330 mm
|
| Height |
240 mm
|
| Depth |
83 mm
|
| Weight |
1.6 kg
|
| Inputs |
WAGO terminal block
|
| Packaging dimensions (W x H x L) |
0.343 x 0.24 x 0.89 m
|
| Gross weight |
1.7 kg
|
| Net weight |
1.6 kg
|
