| Active/passive |
passive
|
| Transmission technology |
100 V
|
| Total power rating |
10 W
|
| Power rating (RMS) |
10/5/2.5 W
|
| Frequency range |
80-19,000 Hz
|
| Number of speakers |
1
|
| Speaker size |
13 cm (5")
|
| SPL |
93 dB (1 W/1 m) 77 dB (EN, 1 W/4 m)
|
| Max. rated SPL |
103 dB (1 m) 88 dB (EN, 4 m)
|
| Radiation angle/beam angle |
H180°/V180° (500 Hz) H80°/V88° (1 kHz) H131°/V126° (2 kHz) H77°/V69° (4 kHz)
|
| Radiation angle, horizontal |
180° (500 Hz) 80° (1 kHz) 131° (2 kHz) 77° (4 kHz)
|
| Radiation angle, vertical |
180° (500 Hz) 88° (1 kHz) 126° (2 kHz) 69° (4 kHz)
|
| Features |
EN 54-24 certification
|
| Housing material |
wood
|
| Colour |
white, RAL 9010
|
| Mounting device |
aluminium bracket
|
| Protected against ball rebound |
yes
|
| Dimensions |
265 x 165 x 88 mm
|
| Width |
265 mm
|
| Height |
165 mm
|
| Depth |
88 mm
|
| Weight |
1.6 kg
|
| Inputs |
WAGO clamp
|
| Packaging dimensions (W x H x L) |
0.268 x 0.168 x 0.92 m
|
| Gross weight |
1.7 kg
|
| Net weight |
1.6 kg
|
