| Active/passive |
passive
|
| Transmission technology |
100 V
|
| Total power rating |
6 W
|
| Power rating (RMS) |
6/3/1.5 W
|
| Frequency range |
100-18,000 Hz
|
| Number of speakers |
1
|
| Speaker size |
20 cm (8")
|
| SPL |
96 dB/W/m
|
| Max. rated SPL |
103 dB
|
| Radiation angle/beam angle |
180° (500 Hz) 160° (1 kHz) 160° (2 kHz) 140° (4 kHz)
|
| Radiation angle, horizontal |
180° (500 Hz) 160° (1 kHz) 160° (2 kHz) 140° (4 kHz)
|
| Radiation angle, vertical |
180° (500 Hz) 160° (1 kHz) 160° (2 kHz) 140° (4 kHz)
|
| Housing material |
Metal
|
| Colour |
White, RAL 9010
|
| Mounting device |
Mounting bracket, mounting screws
|
| Dimensions |
Ø 220 mm x 100 mm
|
| Width |
Ø 220 mm
|
| Height |
Ø 220 mm
|
| Depth |
100 mm
|
| Weight |
2 kg
|
| Inputs |
Pressure clamps
|
| Packaging dimensions (W x H x L) |
0.225 x 0.225 x 0.11 m
|
| Gross weight |
2.1 kg
|
| Net weight |
2 kg
|
