| Active/passive |
passive
|
| Transmission technology |
100 V or low-impedance
|
| Total power rating |
30 W
|
| Power rating (RMS) |
15/7.5/4/2/1 W (100 V) 15 W (8 Ω)
|
| Impedance |
8 Ω
|
| Frequency range |
90-20,000 Hz
|
| System |
2-way
|
| Number of speakers |
2+1
|
| Speaker size |
10 cm (4")
|
| SPL |
87 dB/W/m
|
| Radiation angle/beam angle |
H: 140°/V: 50°
|
| Radiation angle, horizontal |
140°
|
| Radiation angle, vertical |
50°
|
| Housing material |
plastic
|
| Colour |
white
|
| Mounting device |
mounting bracket, end-to-end
|
| Admiss. ambient temp. |
0-40 °C
|
| Dimensions |
128 x 385 x 140 mm
|
| Width |
128 mm
|
| Height |
385 mm
|
| Depth |
140 mm
|
| Weight |
2.8 kg
|
| Inputs |
plug-in screw terminals
|
| Packaging dimensions (W x H x L) |
0.18 x 0.18 x 0.5 m
|
| Gross weight |
3.1 kg
|
| Net weight |
2.84 kg
|
