| Transmission technology |
100 V
|
| Frequency range |
70-19,000 Hz
|
| Power rating (RMS) |
10/5/2.5 W
|
| SPL |
98 dB (1 W/1 m) 81 dB (EN, 1 W/4 m)
|
| Max. rated SPL |
105 dB (1 m) 92 dB (EN, 4 m)
|
| Radiation angle, horizontal |
180° (500 Hz) 180° (1 kHz) 90° (2 kHz) 49° (4 kHz)
|
| Radiation angle, vertical |
180° (500 Hz) 180° (1 kHz) 90° (2 kHz) 49° (4 kHz)
|
| Mounting cutout |
Ø 230 mm
|
| Dimensions |
Ø 252 mm x 105 mm
|
| Outside diameter |
Ø 252 mm
|
| Width |
Ø 252 mm
|
| Height |
Ø 252 mm
|
| Depth |
105 mm
|
| Colour |
White, RAL 9010
|
| Weight |
1.5 kg
|
| Packing unit |
1
|
| Type of speaker |
200
|
| Packaging dimensions (W x H x L) |
0.27 x 0.27 x 0.115 m
|
| Gross weight |
1.7 kg
|
| Net weight |
1.6 kg
|
