| Transmission technology |
100 V
|
| Frequency range |
80-19,000 Hz
|
| Power rating (RMS) |
10/5/2.5 W
|
| SPL |
93 dB (1 W/1 m) 78 dB (EN, 1 W/4 m)
|
| Max. rated SPL |
103 dB (1 m) 88 dB (EN, 4 m)
|
| Radiation angle, horizontal |
180° (500 Hz) 180° (1 kHz) 155° (2 kHz) 76° (4 kHz)
|
| Radiation angle, vertical |
180° (500 Hz) 180° (1 kHz) 155° (2 kHz) 76° (4 kHz)
|
| Mounting cutout |
Ø 140-150 mm
|
| Dimensions |
Ø 167 mm x 90 mm
|
| Outside diameter |
Ø 167 mm
|
| Width |
Ø 167 mm
|
| Height |
Ø 167 mm
|
| Depth |
90 mm
|
| Colour |
white, RAL 9010
|
| Protective class |
IP54
|
| Weight |
1.1 kg
|
| Packing unit |
1
|
| Type of speaker |
130
|
| Packaging dimensions (W x H x L) |
0.187 x 0.187 x 0.090 m
|
| Gross weight |
1.2 kg
|
| Net weight |
1.1 kg
|
