| Type: | Audio transmission |
| Power supply: | 100-240 V AC, 50/60 Hz
12 V DC 1 A |
| Power consumption: | max. 6 W |
| Power connection: | Mains input Coaxial power connector (M) Power supply cord with AC adapter (provided) |
| Number of channels: | 4 |
| Color: | Black |
| Connections: | Input: 2 x line via 3.5 mm jack (stereo) mounting version |
| Output: 4 x Microphone via 3-pin XLR |
| Output: 1 x master via 6.3 mm plug (unbal.) |
| Frequency band: | UHF 823 - 832 MHz; UHF 863 - 865 MHz |
| switch: | on/off switch |
| Material: | Metal |
| Housing design: | (19") 48.3 cm rack installation 1 U |
| Width: | 48,1 cm |
| Height: | 4,5 cm |
| Depth: | 24,5 cm |
| Weight: | 2,50 kg |
