| Peak output power |
160 W
|
| Power rating |
120 W
|
| Power rating at 4 Ω |
120 W
|
| Power rating at 100 V |
120 W
|
| Power rating at 70 V |
120 W
|
| Output impedance |
4 Ω, 70 V/ 100 V
|
| Channels |
1
|
| Inputs |
765 mV (line)
|
| Frequency range |
50-15,000 Hz
|
| Equalizer bass |
± 10 dB/100 Hz
|
| Equalizer treble |
± 10 dB/10 kHz
|
| S/N ratio |
> 80 dB
|
| THD |
< 0.5%
|
| Power supply |
˜ 230 V/50 Hz/300 VA, DC 24 V/9 A
|
| Mains voltage |
~ 230 V
|
| Mains frequency |
50 Hz
|
| Power consumption, operation |
300 VA
|
| Operating voltage (possible alternative) |
DC 24 V
|
| Power supply (possible alternative) |
DC 9 A
|
| Admiss. ambient temp. |
0-40 °C
|
| Width |
482 mm
|
| Height |
88 mm
|
| Depth |
275 mm
|
| Rack units, RU |
2
|
| Weight |
9.5 kg
|
| Connections |
1 x XLR, screw contacts (line in), 1 x XLR (line out), screw contacts (speakers)
|
| Packaging dimensions (W x H x L) |
0.33 x 0.16 x 0.52 m
|
| Gross weight |
11.31 kg
|
| Net weight |
9.86 kg
|
