| No. of channels | 4 |
| No. of inputs | 5 |
| Mic input | 1 mV/600 Ω, 2 x 6.3 mm jack, bal. |
| Line input | 100 mV/10 kΩ, 3 x RCA L/R |
| CD input | - |
| Phono input | - |
| Tape (play) | - |
| Aux input | - |
| Insert input | - |
| Effect return | - |
| Master output | 1-3 V/100 Ω, 2 x RCA L/R |
| Record output | 1 V/100 Ω, 1 x RCA L/R |
| Monitor output | - |
| Booth output | - |
| Aux output | - |
| Insert output | - |
| Effect send | - |
| Control room | - |
| Tape (rec) | - |
| Headphones | ≥ 32 Ω, 2 x 15 mW, 1 x 6.3 mm jack |
| Gooseneck lamp | - |
| USB | - |
| Frequency range | 20-20,000 Hz |
| THD | 0.05% |
| S/N ratio | > 60 dB |
| Crosstalk | - |
| Equalizer bass | ± 12 dB/30 Hz |
| Equalizer midrange | ± 12 dB/1 kHz
(voice only) |
| Equalizer treble | ± 12 dB/12 kHz |
| equalizer | - |
| Talkover | - |
| Phantom power | - |
| Crossfader | - |
| Media player | - |
| Amplifier | - |
| Power supply | ∼ 230 V/50 Hz/10 VA |
| Mains voltage | ∼ 230 V |
| Mains frequency | 50 Hz |
| Power consumption, operation | 10 VA |
| Operating voltage (possible alternative) | - |
| Power supply (possible alternative) | - |
| Admiss. ambient temp. | 0-40 °C |
| Width | 482 mm |
| Height | 45 mm |
| Depth | 180 mm |
| Rack spaces, RS | 1 |
| Weight | 2.25 kg |
