Teknisk specifikationer Contact resistance < 10 mΩ Dielectric strength 0,5 kVdc Rated current per contact depends on mated connector A Cable O.D. ≤ 6 mm Lifetime 1000 mating cycles Wire size 24 AWG RW / Straight no Bushing Steel sp. Contact plating 2 µm Ni Contacts Brass (CuZn39Pb3) Insert Polyamide (PA 6.6 30 % GR) Shell ABS Strain relief CRIMP type snce plated Solderability Complies with IEC 68-2-20 Temperature range -20 °C to +70 °C
