¦High Performance Low Noise Design
¦Six Discrete Inputs (2 x Mic / 2 x Stereo Line Level)
¦Switchable +48v Phantom Power (CH1 & CH2)
¦High and Low EQ on Each Input Channel
¦Integrated Stereo Multi-FX with Adjustable Sends & Returns
¦Stereo LED Metering
¦Independent Level Controls for Main and Headphone/Monitor Outputs
¦Integrated Class Compliant Plug-and-Play USB Audio for Mac & PC
Input Connections
XLR & ¼-inch Balanced Combi-jack (CH 1 & CH2)
¼-inch TRS Balanced (CH3 & CH4)
RCA Unbalanced (CH5 & CH6), RCA Aux Loop In (L & R)
Output Connections ¼-inch TRS Balanced Main Mix Outputs
¼-inch TRS Stereo Output & Monitor Outputs
RCA Loop Out (L & R)
Signal to Noise Ratio >90dB Typical (Ref 0dBu)
Maximum Input Level +4dBu (Mic), +20dBu (1/4-inch Input)
Maximum Output Level +15dBu Main Mix Outputs
Maximum Gain >54dB (Mic), >39dB (Instrument), 10dB (Stereo Monitor & Line Out)
USB Computer Interface USB Class Compliant plug-and-play Mac / PC Interface
Power 15VAC @ 500mA (Adaptor Included)
Dimensions 1.9"H x 7.4"W x 8.5"D (47mm x 186mm x 215mm)
Weight 3.24 lbs (1.47 kg)
