| Active/passive | passive |
| Transmission method | 100 V |
| Impedance | - |
| Frequency range | 130-18,000 Hz |
| Power rating | - |
| Max. power | - |
| THD | - |
| S/N ratio | - |
| Input signal | - |
| System | 130 mm full range speaker |
| Full range speaker | - |
| Bass speaker | - |
| Midrange speaker | - |
| Tweeter | - |
| Number of speakers | 1 |
| Speaker size | 13 cm (5") |
| Power rating | 16/8/4 W |
| Peak music power output | - |
| Sensitivity | 89.9 dB/W/m |
| Max. rated SPL | 101 dB |
| Radiation angle, horizontal | 196° (1 kHz)
132° (2 kHz)
170° (4 kHz) |
| Radiation angle, vertical | 196° (1 kHz)
132° (2 kHz)
170° (4 kHz) |
| Features | |
| Housing material | ABS |
| Colour | white, RAL 9010 |
| Mounting facility | canopy |
| Protected against ball rebound | - |
| Protective class | IP35 |
| Admiss. ambient temp. | -20 °C to +80 °C |
| Power supply | - |
| Width | Ø 185 mm |
| Height | 157 mm |
| Depth | - |
| Weight | 1.6 kg |
| Inputs | ceramic terminal with thermal fuse |
| Outputs | - |
| Replacement voice coil | |
| Other features | - |
| Accessories | |
