| Peak output power | - |
| Power rating | 60 W |
| Power rating at 2 Ω | - |
| Power rating at 4 Ω | - |
| Power rating at 8 Ω | - |
| Power rating at 16 Ω | - |
| Power rating at 100 V | - |
| Power rating with 4 Ω bridged operation | - |
| Power rating with 8 Ω bridged operation | - |
| Output impedance | - |
| Channels | 1 |
| Zones | 1 |
| Inputs | 4.5 mV/600 Ω (channel 1), 4.5 mV/120 mV (channels 2-3), 60 mV (channels 4-5) 90 mV (tel.) |
| Attenuation factor | - |
| Frequency range | 60-15,000 Hz |
| Crossover network | - |
| Crossover frequency | - |
| Integrated limiter | - |
| Equalizer bass | yes |
| Equalizer midrange | - |
| Equalizer treble | yes |
| S/N ratio | 72 dB (mic, channels 1-3) 85 dB (line, channels 2-5) |
| Crosstalk attenuation | - |
| THD | < 0.5% |
| Phantom power | 48 V |
| Mains voltage | ∼ 230 V |
| Mains frequency | 50 Hz |
| Power consumption, operation | 160 VA |
| Power consumption, standby | - |
| Standby current | - |
| Operating voltage (possible alternative) | DC 24 V |
| Power supply (possible alternative) | 4.2 A |
| Admiss. ambient temp. | 0-40 °C |
| Width | 320 mm |
| Height | 95 mm |
| Depth | 245 mm |
| Rack spaces, RS | - |
| Weight | 4.5 kg |
| Connections | 1 x XLR (channel 1), 2 x 6.3 mm jack (channels 2-3), 2 x RCA L/R (channels 4-5), 2 x RCA (record out), 1 x F jack (FM/DAB+), screw terminals (tel. input, MOH, DC 24 V, speakers, mute) |
| Packing dimensions (W x H x L) | - |
| Gross weight | 5.17 kg |
| Net weight | 4.48 kg |
