| Power supply: | 100-240 V AC, 50/60 Hz |
| Power consumption: | 230 W |
| IP classification: | IP65 |
| Protection class: | Protection class I |
| Power connection: | Mains input via IP T-Con (M) mounting version power supply cord with safety plug |
| Cable construction: | 3 x 2.5 mm² H07RN-F |
| Power output: | IP T-Con (F) mounting version |
| Lamp type: | LED lamp |
| LED type: | 36 x 10 W warm white (WW)
48 x 0.6 W red (R)
48 x 1 W amber (A) |
| Flash rate: | 1 - 33 Hz |
| DMX channels: | 1; 4; 6; 12; 16; 21; 24; 34 |
| DMX input: | 3-pin XLR (M) mounting version IP
5-pin XLR (M) mounting version IP |
| DMX output: | 3-pin XLR (F) mounting version IP
5-pin XLR (F) mounting version IP |
| Cooling: | Passive convection cooling |
| Control: | Stand-alone; DMX; RDM; master/slave function |
| Preprogrammed in: | Light Captain |
| Projection: | Flicker-free |
| DMX features: | RDM For bidirectional communication over the DMX line |
| DMX fail mode: | Hold; blackout |
| Housing color: | Black |
| Attachment system: | 2x panning and tilting mounting bracket for ceiling or wall installation in most varying angles
2x omega bracket |
| Display type: | Multicolor LCD display |
| Diameter mounting holes: | 2 x Ø12mm |
| Use of brands: | Built with SEETRONIC connector |
| Material: | Aluminum casting |
| Dimensions: | Length: 100.5 cm
Width: 14.0 cm
Height: 14.7 cm |
| Weight: | 8.25 kg |
| Noise classification: | Class 1 (very slight noise, suitable for noise-sensitive environments) |
| Legal specifications |
| Special product: | Not designed for household room illumination |
| Intended use: | Show effect lighting |
