| Power supply: | 100-240 V AC, 50/60 Hz
AC |
| Power consumption: | Approx. 190 W |
| IP classification: | IP20 |
| Protection class: | Protection class I |
| Power connection: | Mains input via P-Con (blue), mounting version power supply cord with safety plug (provided) |
| Fuse: | 5 x 20 mm, T 2.5 A fuse replaceable |
| Lamp type: | LED lamp |
| LED type: | 20 x 10 W high-power R/G/B/WW |
| Flash rate: | 0.5 - 25 Hz |
| DMX channels: | 2; 3; 4; 5; 10 |
| DMX input: | 1 x 3-pin XLR (M) mounting version |
| DMX output: | 1 x 3-pin XLR (F) mounting version Bypass |
| Cooling: | 1 x cooling fan at the base |
| Control: | IR remote control; DMX; QuickDMX (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional); stand-alone; master/slave function; sound to light via microphone |
| Preprogrammed in: | Light´J; Light Captain |
| Projection: | Flicker-free |
| DMX fail mode: | Blackout; hold; auto; full on |
| Housing color: | Black matte |
| Attachment system: | Omega bracket |
| Display type: | Monochrome 4 digit 7-segment LED display |
| USB port: | 1 x type A |
| Material: | Metal, 1.2 mm, painted |
| Dimensions: | Height: 26.6 cm
Diameter: Ø 24.25 cm |
| Weight: | 5.30 kg |
| Noise classification: | Class 2 (slight noise) |
| Power cord |
| Cable construction: | 3 x 1.0 mm² H05VV-F |
| Cable length: | Approx. 1.4 m |
| Omega bracket |
| Diameter mounting holes: | 1 x Ø13mm |
| Material thickness: | 3 mm |
| Dimensions: | Length: 14 cm
Width: 3.5 cm
Height: 3.5 cm |
| Battery |
| Battery: | 1 x button cell 3.0 V CR2025 lithium manganese built-in |
| Legal specifications |
| Special product: | Not designed for household room illumination |
| Intended use: | Show effect lighting |
