Elation PROTEUS BRUTUS, 1200W 6,500K Bright White LED IP65

Fjernlager
Kontakt os om leveringstid
Bedømmelse for Elation PROTEUS BRUTUS, 1200W 6,500K Bright White LED IP65
Produktet er endnu ikke bedømt

115.620,00DKK ved 1 stk.

Vis uden moms

The PROTEUS BRUTUS™ is an extremely bright IP65 rated LED Wash Beam FX fixture offering high intensity wash and effects qualities in any environment.

FEATURES

High Efficiency 1200W 6,500K Peak Field LED Engine
Up to 75.000 Total Lumen Fixture Output
CMY Color Mixing and Variable CTO
6 Position Color Wheel, High CRI, UV filter
Complete FX System featuring Rotating Gobos, Animation, Iris, Frost
Optional Full Blackout Framing Module
Wide Zoom Range from 4° to 45° / Large 220mm (8.7”) Front Aperture
FIL (Foam In Lay) Polyurethane Foam Packaging Included

SOURCE

1200W 6,500K Bright White LED Engine
30,000 Hour Average LED Life*
*Lamp Life may vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control and Dimming.

PHOTOMETRIC DATA

75,000 Total Lumen Output
CRI 70+ (82+ with HCRI Filter)
2:1 Peak Field
Zoom Range 4.5° - 45°
Beam Angle 4.4° - 39.4°
Field Angle 6.8° - 49.7°

EFFECTS

Motorized Zoom (220mm / 8.7 in Front Aperture)
Full 360° Bi-Directional Animation Wheel
Variable Frost Filter
Motorized Iris with Variable Pulse Effects
Variable 16-bit Dimming Curve Modes
High Speed Electronic Shutter and Strobe
DMX Controllable LED Refresh Rate

Pan Angle: 540°/630°
Tilt Angle: 266°

COLOR

CMY Color Mixing
Linear CTO Color Correction
6 Dichroic Colors including High CRI Filter and UV

GOBOS

5 Rotating / Indexing Interchangeable Beam Shaping + FX Gobos

OPTIONAL FRAMING MODULE

1237000260 Framing Modul for Brutus

4 Rotating Full Blackout Framing Blades
+/-45° Framing Indexing

CONTROL / CONNECTIONS

4 DMX Channel Modes (25 /34 / 36 / 56)
16-bit Pan, Tilt and Dimming Control
Motorized Focus
DMX, RDM, Art-NET, sACN Protocol Support
(6) Button Touch Control Panel
Full Color 180° Reversible LCD Menu Display
Hibernation Mode (Power Save)
5pin XLR DMX In/Out
IP65 RJ45 ethernet In/Out
IP65 Locking Power Cable In
With Wired Digital Communication Network

SIZE / WEIGHT

Length: 643.6mm (25.3 in)
Width: 456.9mm (18 in)
Height: 869mm (34.2 in)
Weight: 47.2kg (104.1 lbs.)

ELECTRICAL / THERMAL

AC 120-240V 50/60Hz
Max Power Consumption 1,700W
-20°C to 45°C (14°F to 113°F)

Varenr.: M-1237000259
